3.3.22 TexturedSphereRotationByKeyInput

In OpenGL, you can map a texture to a solid sphere by using gluSphere and gluQuadricTexture APIs in OpenGL GLU library.
In this example, we have used the OpenGLTexturedSphere.

OpenGLObject

  OpenGLTexture

    OpenGLTexture2D

      OpenGLTexturedSphere


The following TexturedSphereRotationByKeyInput is a simple example to draw a textured shpere and rotate it by Left or Rigth keys.

In this example, we have used the world map of 'world.topo.bathy.200412.3x5400x2700.jpg' file in the following page.
NASA VISIBLE EARTH
December, Blue Marble Next Generation w/ Topography and Bathymetry
Credit: Reto Stockli, NASA Earth Observatory

We have used the following world map file based on the 'world.topo.bathy.200412.3x5400x2700.jpg'.







We have used the following Viking's Mars 'mar0kuu2.jpg' created by Caltech/JPL/USGS in the SOLAR SYSTEM SIMULATOR.







We have also used the following Jupiter 'PIA07782_hires.jpg' in the JPL Cassini's Best Maps of Jupiter.






//
//TexturedSphereRotationByKeyInput.cpp
//Copyright (c) 2017 Antillia.com TOSHIYUKI ARAI. ALL RIGHTS RESERVED.

// We have used 'world.topo.bathy.200412.3x5400x2700.jpg' file in the following page.
//
//http://visibleearth.nasa.gov/view.php?id=73909
//
//December, Blue Marble Next Generation w/ Topography and Bathymetry
//Credit: Reto St?ckli, NASA Earth Observatory

//2017/11/27 Updated.

#include <oz++/opengl/OpenGLMainView.h>
#include <oz++/opengl/OpenGLView.h>
#include <oz++/opengl/OpenGLGC.h>
#include <oz++/opengl/OpenGLLight.h>
#include <oz++/opengl/OpenGLMaterial.h>
#include <oz++/opengl/OpenGLTexturedSphere.h>

namespace OZ {

class MainView :public OpenGLMainView {

private:
  //Inner class starts
  class SimpleView: public OpenGLView {
  private:
    OpenGLGC          gc;
    SmartPtr<OpenGLTexturedSphere> texture;
    float                       angle;
    Vertex3                     axis;
  public:
    virtual void display()
    {
      if (texture) {
        gc.matrixMode(GL_PROJECTION);
        gc.loadIdentity();
        gc.perspective(16.0, (double)width() / (double)height(), 0.5, 100.0);
        gc.matrixMode(GL_MODELVIEW);

        gc.clear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT);
        gc.loadIdentity();

        gc.clearColor(0.1, 0.1, 0.2, 1.0);
        gc.enable(GL_CULL_FACE);
        //2017/11/27 Added the following line
        gc.cullFace(GL_FRONT);
        gc.enable(GL_LIGHTING);

        gc.enable(GL_DEPTH_TEST);
        gc.color(1.0f, 1.0f, 1.0f);
        gc.lookAt(0.0, 18.0, 4.0, 0.0, 0.0, 0.0, 0.0, 100.0, 0.0);

        gc.translate(0.0f, 0.0f, 0.0f);

        gc.rotate(angle, axis.x, axis.y, axis.z);

        OpenGLLight light(GL_LIGHT0);
        //2017/11/27 Modified lightPosition
        GLfloat lightPosition[] = {-10, -10, -10, 1.0};
        light.position(lightPosition);

        GLfloat white[] = {1.0f, 1.0f, 1.0f, 1.0f};
        GLfloat blue[]  = {0.0f, 0.0f, 1.0f, 1.0f};
        GLfloat shininess[] = {100.0};
        OpenGLMaterial material(GL_FRONT);
        material.diffuse(blue);
        material.specular(white);
        material.shininess(shininess);

        texture -> draw(&gc);
      }
    }

    virtual void resize(int w, int h)
    {
      if (w == 0 || h == 0) {
        return;
      }

      gc.matrixMode(GL_PROJECTION);
      gc.loadIdentity();
      gc.perspective(16.0, (double)w/(double)h, 0.5, 100.0);

      gc.matrixMode(GL_MODELVIEW);
    }

    virtual void initialize()
    {
      //2017/11/27 Modified axis value.
      axis.x = -10.0f;
      axis.y = -50.0f;
      axis.z = 80.0f;
      gc.enable(GL_DEPTH_TEST);
      gc. enable(GL_TEXTURE_2D);
      try {
        // The 'world.topo.bathy.200412.3x860x430.jpg' used here is based on
        // 'world.topo.bathy.200412.3x5400x2700.jpg' in the following page.
        //
        //http://visibleearth.nasa.gov/view.php?id=73909
        //
        //December, Blue Marble Next Generation w/ Topography and Bathymetry
        //Credit: Reto St?ckli, NASA Earth Observatory
        const char* imageFileName = "../../images/world.topo.bathy.200412.3x860x430.jpg";

        texture = new OpenGLTexturedSphere(imageFileName, 2.5f, 40, 40);

      } catch (Exception& ex) {
        caught(ex);
      }

    }
    virtual void keyPress(Event& event)
    {
      KeySym k = event.getKeySym();
      if (k == XK_Left) {
        angle -= 2.0f;
        sendExposeEvent();
      }
      if (k == XK_Right) {
        angle += 2.0f;
        sendExposeEvent();
      }
    }

    virtual void keyRelease(Event& event)
    {
      //Do nothing here
    }

  public:
    SimpleView(OpenGLMainView* parent, const char* name, Args& args)
    :OpenGLView(parent, name, args),
    angle(0.0f)
    {
    }

    ~SimpleView()
    {
    }
  };
  //Inner class ends.

private:
  SmartPtr<SimpleView>  view;


public:
  MainView(OpenGLApplication& applet, const char* name, Args& args)
  :OpenGLMainView(applet, name, args)
  {
    Args ar;
    ar.set(XmNopenGLBufferType, (XtArgVal)getBufferType());
    view = new SimpleView(this, "", ar);
  }

  ~MainView()
  {
  }
};
}

//
int main(int argc, char** argv)
{
  try {
    const char*  name = argv[0];
    OpenGLApplication applet(name, argc, argv);

    Args args;
    args.set(XmNwidth,  400);
    args.set(XmNheight, 400);

    MainView view(applet, name, args);
    view.realize();

    applet.run();

  } catch (Exception& ex) {
    caught(ex);
  }
  return 0;
}
