OZ++ Sample: StructureNotifyHandler |
/******************************************************************************
*
* Copyright (c) 2015 Antillia.com TOSHIYUKI ARAI. ALL RIGHTS RESERVED.
*
* Redistribution and use in source and binary forms, with or without
* modification, are permitted provided that the following conditions
* are met:
* 1. Redistributions of source code must retain the above copyright
* notice, this list of conditions, and the following disclaimer.
*
* 2. The name of the author may not be used to endorse or promote products
* derived from this software without specific prior written permission.
*
* THIS SOFTWARE IS PROVIDED BY THE AUTHOR ``AS IS'' AND ANY EXPRESS OR
* IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
* OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
* IN NO EVENT SHALL THE AUTHOR BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,
* SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,
* PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS;
* OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY,
* WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR
* OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF
* ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
*
*
* StructureNotifyHandler.cpp
*
*****************************************************************************/
#include <oz++/motif/ApplicationView.h>
#include <oz++/motif/Form.h>
#include <oz++/motif/BulletinBoard.h>
#include <oz++/motif/ScrollBar.h>
#include <oz++/motif/RenderTable.h>
#include <oz++/motif/DC.h>
/*
#define KeyPress 2
#define KeyRelease 3
#define ButtonPress 4
#define ButtonRelease 5
#define MotionNotify 6
#define EnterNotify 7
#define LeaveNotify 8
#define FocusIn 9
#define FocusOut 10
#define KeymapNotify 11
#define Expose 12
#define GraphicsExpose 13
#define NoExpose 14
#define VisibilityNotify 15
#define CreateNotify 16
#define DestroyNotify 17
#define UnmapNotify 18
#define MapNotify 19
#define MapRequest 20
#define ReparentNotify 21
#define ConfigureNotify 22
#define ConfigureRequest 23
#define GravityNotify 24
#define ResizeRequest 25
#define CirculateNotify 26
#define CirculateRequest 27
#define PropertyNotify 28
#define SelectionClear 29
#define SelectionRequest 30
#define SelectionNotify 31
#define ColormapNotify 32
#define ClientMessage 33
#define MappingNotify 34
#define GenericEvent 35
*/
namespace OZ {
class MainView :public ApplicationView {
private:
SmartPtr<BulletinBoard> bboard;
SmartPtr<BulletinBoard> tablet;
SmartPtr<ScrollBar> hscrollBar;
SmartPtr<ScrollBar> vscrollBar;
SmartPtr<RenderTable> renderTable;
int width;
int height;
void draw(Event& event)
{
XEvent* xevent = (XEvent*)event.getXEvent();
DC dc(this);
dc.setRenderTable(renderTable->get());
const char* string = (const char*)event.getClientData();
CompoundString cs(string);
cs.move(50, 100);
cs.draw(&dc);
printf("%s\n", string);
}
/*
typedef struct
{
int reason;
XEvent * event;
int value;
int pixel;
} XmScrollBarCallbackStruct;
*/
void vscValueChanged(Action& action)
{
XmScrollBarCallbackStruct* cbs = (XmScrollBarCallbackStruct*)action.getCallData();
printf("vscValueChanged reason=%d %d\n", cbs->reason, cbs->value);
}
void vscDrag(Action& action)
{
XmScrollBarCallbackStruct* cbs = (XmScrollBarCallbackStruct*)action.getCallData();
printf("vscDrag reason=%d %d\n", cbs->reason, cbs->value);
}
void vscIncrement(Action& action)
{
XmScrollBarCallbackStruct* cbs = (XmScrollBarCallbackStruct*)action.getCallData();
printf("vscIncrement reason=%d %d\n", cbs->reason, cbs->value);
}
void vscDecrement(Action& action)
{
XmScrollBarCallbackStruct* cbs = (XmScrollBarCallbackStruct*)action.getCallData();
printf("vscDecrement reason=%d %d\n", cbs->reason, cbs->value);
}
void hscValueChanged(Action& action)
{
XmScrollBarCallbackStruct* cbs = (XmScrollBarCallbackStruct*)action.getCallData();
printf("hscrolled reason=%d %d\n", cbs->reason, cbs->value);
}
void hscDrag(Action& action)
{
XmScrollBarCallbackStruct* cbs = (XmScrollBarCallbackStruct*)action.getCallData();
printf("hscDrag reason=%d %d\n", cbs->reason, cbs->value);
}
void hscIncrement(Action& action)
{
XmScrollBarCallbackStruct* cbs = (XmScrollBarCallbackStruct*)action.getCallData();
printf("hscIncrement reason=%d %d\n", cbs->reason, cbs->value);
}
void hscDecrement(Action& action)
{
XmScrollBarCallbackStruct* cbs = (XmScrollBarCallbackStruct*)action.getCallData();
printf("hscDecrement reason=%d %d\n", cbs->reason, cbs->value);
}
void structureNotify(Event& event)
{
printf("structureNotify");
XEvent* xe = event.getXEvent();
printf("Type %d\n", xe->type);
if (xe -> type == MapNotify) {
layout();
}
if (xe -> type == ConfigureNotify) {
XConfigureEvent xce = xe->xconfigure;
// if (xce.width != width ||
// xce.height != height) {
width = xce.width;
height = xce.height;
printf("Resized width=%d height=%d\n",
width, height);
bboard -> set(XmNwidth, width);
bboard -> set(XmNheight,height);
layout();
//}
}
}
void layout()
{
Dimension w = bboard -> width();
Dimension h = bboard -> height();
printf("w=%d h=%d\n", w, h);
tablet -> resize(4, 4, (w-22), (h-22), 1);
vscrollBar -> resize ((w-20), 4,
14, (h - 20 - 4), 0);
hscrollBar -> resize( 4, (h-20),
(w - 20 -4), 14, 0);
}
public:
MainView(Application& applet, const char* name, Args& args)
:ApplicationView(applet, name, args)
{
width = 0;
height = 0;
Args ar;
ar.set(XmNfontName, "Times-a");
ar.set(XmNfontSize, 24);
renderTable = new RenderTable(this, "", ar);
ar.reset();
ar.set(XmNborderWidth, 1);
bboard = new BulletinBoard(this, "", ar);
bboard -> addEventHandler(StructureNotifyMask, this,
(Handler)&MainView::structureNotify, NULL);
ar.reset();
tablet = new BulletinBoard(this, "",ar);
ar.reset();
ar.set(XmNsliderSize, 100);
ar.set(XmNmaximum, 1000+100);
ar.set(XmNorientation, XmVERTICAL);
vscrollBar = new ScrollBar(bboard, "", ar);
vscrollBar -> addCallback(XmNvalueChangedCallback, this,
(Callback)&MainView::vscValueChanged, NULL);
vscrollBar -> addCallback(XmNdragCallback, this,
(Callback)&MainView::vscDrag, NULL);
vscrollBar -> addCallback(XmNincrementCallback, this,
(Callback)&MainView::vscIncrement, NULL);
vscrollBar -> addCallback(XmNdecrementCallback, this,
(Callback)&MainView::vscDecrement, NULL);
ar.reset();
ar.set(XmNsliderSize, 10);
ar.set(XmNmaximum, 20+10);
ar.set(XmNorientation, XmHORIZONTAL);
hscrollBar = new ScrollBar(bboard, "", ar);
hscrollBar -> addCallback(XmNvalueChangedCallback, this,
(Callback)&MainView::hscValueChanged, NULL);
hscrollBar -> addCallback(XmNdragCallback, this,
(Callback)&MainView::hscDrag, NULL);
hscrollBar -> addCallback(XmNincrementCallback, this,
(Callback)&MainView::hscIncrement, NULL);
hscrollBar -> addCallback(XmNdecrementCallback, this,
(Callback)&MainView::hscDecrement, NULL);
bboard -> addEventHandler(StructureNotifyMask, this,
(Handler)&MainView::structureNotify, NULL);
}
~MainView()
{
}
};
}
//
int main(int argc, char** argv)
{
try {
const char* appclass = argv[0];
Application applet(appclass, argc, argv);
Args args;
args.set(XmNgeometry, "300x300");
MainView view(applet, argv[0], args);
view.realize();
applet.run();
} catch (Exception& ex) {
caught(ex);
}
return 0;
}
