/****************************************************************************** * * Copyright (c) 2019 Antillia.com TOSHIYUKI ARAI. ALL RIGHTS RESERVED. * * Redistribution and use in source and binary forms, with or without * modification, are permitted provided that the following conditions * are met: * 1. Redistributions of source code must retain the above copyright * notice, this list of conditions, and the following disclaimer. * * 2. The name of the author may not be used to endorse or promote products * derived from this software without specific prior written permission. * * THIS SOFTWARE IS PROVIDED BY THE AUTHOR ``AS IS'' AND ANY EXPRESS OR * IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES * OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. * IN NO EVENT SHALL THE AUTHOR BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, * SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, * PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; * OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, * WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR * OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF * ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. * * * ImageSharpening.cpp * *****************************************************************************/ //2017/05/15 //2019/01/03 #include <opencv2/stitching.hpp> #include <oz++/motif/Label.h> #include <oz++/motif/RowColumn.h> #include <oz++/motif/LabeledTrackBar.h> #include <oz++/opencv/OpenCVScaleComboBox.h> #include <oz++/opencv/OpenCVMainView.h> #include <oz++/opencv/OpenCVImageView.h> #include <oz++/motif/FileOpenDialog.h> namespace OZ { class MainView :public OpenCVMainView { private: /////////////////////////////////////////////// //Inner classes start. class OriginalImageView: public OpenCVImageView { private: cv::Mat originalImage; cv::Mat scaledImage; virtual void display() { show(scaledImage); } public: OriginalImageView(View* parent, const char* name, Args& args) :OpenCVImageView(parent, name, args) { try { const char* filename = (const char*)args.get(XmNimageFileName); int imageLoadingFlag = args.get(XmNimageLoadingFlag); int scalingRatio = (int)args.get(XmNimageScalingRatio); loadImage(filename, imageLoadingFlag, scalingRatio); } catch (OZ::Exception ex) { caught(ex); } } ~OriginalImageView() { } void loadImage(const char* filename, int imageLoadingFlag= CV_LOAD_IMAGE_COLOR, int scalingRatio=100) { try { originalImage = readImage(filename, imageLoadingFlag); scaleImage(originalImage, scaledImage, scalingRatio); } catch (OZ::Exception& ex) { caught(ex); } } void rescale(int scalingRatio) { scaledImage.release(); scaleImage(originalImage, scaledImage, scalingRatio); } }; class SharpenedImageView: public OpenCVImageView { private: cv::Mat originalImage; cv::Mat sharpenedImage; cv::Mat scaledImage; //The scale image is displayed on this image view. virtual void display() { show(scaledImage); } public: SharpenedImageView(View* parent, const char* name, Args& args) :OpenCVImageView(parent, name, args) { try { const char* filename = (const char*)args.get(XmNimageFileName); int imageLoadingFlag = args.get(XmNimageLoadingFlag); int scalingRatio = (int)args.get(XmNimageScalingRatio); loadImage(filename, imageLoadingFlag, scalingRatio); } catch (OZ::Exception ex) { caught(ex); } } ~SharpenedImageView() { } void loadImage(const char* filename, int imageLoadingFlag= CV_LOAD_IMAGE_COLOR, int scalingRatio=100) { try { originalImage = readImage(filename, imageLoadingFlag); sharpenedImage = originalImage.clone(); } catch (OZ::Exception& ex) { caught(ex); } } void rescale(int scalingRatio) { scaledImage.release(); scaleImage(sharpenedImage, scaledImage, scalingRatio); } void sharpen(int ksize, int sigma, int scalingRatio) { ksize = (ksize/2)*2 + 1; //void GaussianBlur(const Mat& src, Mat& dst, Size ksize, // double sigmaX, // double sigmaY = 0, // int borderType = BORDER_DEFAULT) cv::Mat newImage = cv::Mat::zeros(originalImage.size(), originalImage.type() ); cv::GaussianBlur(originalImage, newImage, cv::Size(ksize, ksize), (double)sigma, //sigmaX, (double)sigma, //sigmaY BORDER_DEFAULT); // void addWeighted(InputArray src1, double alpha, InputArray src2, // double beta, double gamma, OutputArray dst, int dtype=-1) double alpha = 2.5; double beta = 1.0 - alpha; cv::addWeighted(originalImage, alpha, newImage, beta, 0.0, newImage); sharpenedImage = newImage; scaleImage(sharpenedImage, scaledImage, scalingRatio); } }; //Inner classes end. private: StringT<char> imageFile; int imageLoadingFlag; int imageScalingRatio; //percentage SmartPtr<Label> label; SmartPtr<OriginalImageView> originalImage; SmartPtr<SharpenedImageView> sharpenedImage; SmartPtr<RowColumn> controlPane; SmartPtr<OpenCVScaleComboBox> scaleComboBox; SmartPtr<LabeledTrackBar> ksizeTrackBar; int ksize; SmartPtr<LabeledTrackBar> sigmaTrackBar; int sigma; SmartPtr<FileOpenDialog> fileDialog; public: void scaleChanged(Action& action) { int val = scaleComboBox->getScale(); if (val > 0 && imageScalingRatio != val) { imageScalingRatio = val; originalImage -> rescale(imageScalingRatio); sharpenedImage -> rescale(imageScalingRatio); } } void ksizeChanged(Action& action) { ksize = (int)ksizeTrackBar->get(XmNvalue); printf("ksizeChanged ksize=%d\n", ksize); sharpenedImage -> sharpen(ksize, sigma, imageScalingRatio); } void sigmaChanged(Action& action) { sigma = sigmaTrackBar->get(XmNvalue); printf("sigmaChanged sigma=%d\n", sigma); sharpenedImage -> sharpen(ksize, sigma, imageScalingRatio); } void cancel(Action& action) { fileDialog->popdown(); } void fileOpen(Action& action) { fileDialog->popup(); } void updateLabel(const char* filename) { CompoundString cs(filename); label->set(XmNlabelString, cs); } void ok(Action& action) { try { imageFile = fileDialog->getFileName(); const char* filename = (const char*)imageFile; printf("filename: %s\n", filename); fileDialog->popdown(); originalImage->invalidate(); originalImage->loadImage(filename, imageLoadingFlag, imageScalingRatio); originalImage->invalidate(); sharpenedImage ->loadImage(filename, imageLoadingFlag, imageScalingRatio); sharpenedImage -> sharpen(ksize, sigma, imageScalingRatio); updateLabel(filename); resize(width(), height()); flush(); } catch (OZ::Exception& ex) { caught(ex); } } void resize(Dimension w, Dimension h) { int CP_WIDTH = 200; int LB_HEIGHT = 30; int ww = w-CP_WIDTH; int hh = h - LB_HEIGHT; if (label && originalImage && sharpenedImage && controlPane ) { label -> reshape(0, 0, w, LB_HEIGHT); originalImage-> reshape(0, LB_HEIGHT, ww/2, hh); sharpenedImage -> reshape(ww/2, LB_HEIGHT, ww/2-1, hh); controlPane -> reshape(ww-1, LB_HEIGHT, CP_WIDTH+1, hh); //The following two lines are a workaround to erase garbage. controlPane -> unmap(); controlPane -> map(); } flush(); } public: MainView(OpenCVApplication& applet, const char* name, Args& args) :OpenCVMainView(applet, name, args) { BulletinBoard* bboard = getBulletinBoard(); imageFile = "../images/YellowFlower.png"; imageLoadingFlag = CV_LOAD_IMAGE_COLOR; imageScalingRatio = 60; //% try { Args ar; CompoundString fileNamecs(imageFile); ar.set(XmNlabelString, fileNamecs); ar.set(XmNalignment, XmALIGNMENT_BEGINNING); label = new Label(bboard, "", ar); ar.reset(); ar.set(XmNimageFileName, imageFile); ar.set(XmNimageLoadingFlag, imageLoadingFlag); ar.set(XmNimageScalingRatio, imageScalingRatio); originalImage = new OriginalImageView(bboard, "", ar); ar.reset(); ar.set(XmNimageFileName, imageFile); ar.set(XmNimageLoadingFlag, imageLoadingFlag); ar.set(XmNimageScalingRatio, imageScalingRatio); sharpenedImage = new SharpenedImageView(bboard, "", ar); ar.reset(); controlPane = new RowColumn(bboard, "", ar); const char* defaultScale = "60%"; ar.reset(); CompoundString scaler("Scale"); ar.set(XmNlabelString, scaler); ar.set(XmNdefaultScale, defaultScale); scaleComboBox = new OpenCVScaleComboBox(controlPane, "", ar); scaleComboBox->addCallback(XmNselectionCallback, this, (Callback)&MainView::scaleChanged, NULL); ksize = 7; ar.reset(); CompoundString ksizecs("KernelSize[0,31]"); ar.set(XmNlabelString, scaler); ar.set(XmNminimum, 0); ar.set(XmNmaximum, 31); ar.set(XmNvalue, ksize); ar.set(XmNtitleString, ksizecs); ksizeTrackBar = new LabeledTrackBar(controlPane, "", ar); //ksizeTrackBar->addCallback(XmNdragCallback, this, ksizeTrackBar->addCallback(XmNvalueChangedCallback, this, (Callback)&MainView::ksizeChanged, NULL); ar.reset(); CompoundString sigmacs("Sigma[0,20]"); sigma = 12; ar.set(XmNlabelString, scaler); ar.set(XmNminimum, 0); ar.set(XmNmaximum, 20); ar.set(XmNvalue, sigma ); ar.set(XmNtitleString, sigmacs); sigmaTrackBar = new LabeledTrackBar(controlPane, "", ar); //sigmaTrackBar->addCallback(XmNdragCallback, this, sigmaTrackBar->addCallback(XmNvalueChangedCallback, this, (Callback)&MainView::sigmaChanged, NULL); sharpenedImage -> sharpen(ksize, sigma, imageScalingRatio); ar.reset(); fileDialog = new FileOpenDialog(this, "FileOpenDialog", ar); fileDialog -> getOkButton() -> addCallback(XmNactivateCallback, this, (Callback)&MainView::ok, NULL); sendConfigureEvent(); } catch(OZ::Exception& ex) { caught(ex); } } ~MainView() { } }; } // int main(int argc, char** argv) { try { const char* appclass = argv[0]; OpenCVApplication applet(appclass, argc, argv); Args args; args.set(XmNwidth, 900); args.set(XmNheight, 380); MainView view(applet, argv[0], args); view.realize(); applet.run(); } catch (OZ::Exception& ex) { caught(ex); } return 0; }
