OZ++ Sample: VertexAndIndexBufferARB |
/******************************************************************************
*
* Copyright (c) 2016 Antillia.com TOSHIYUKI ARAI. ALL RIGHTS RESERVED.
*
* Redistribution and use in source and binary forms, with or without
* modification, are permitted provided that the following conditions
* are met:
* 1. Redistributions of source code must retain the above copyright
* notice, this list of conditions, and the following disclaimer.
*
* 2. The name of the author may not be used to endorse or promote products
* derived from this software without specific prior written permission.
*
* THIS SOFTWARE IS PROVIDED BY THE AUTHOR ``AS IS'' AND ANY EXPRESS OR
* IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
* OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
* IN NO EVENT SHALL THE AUTHOR BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,
* SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,
* PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS;
* OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY,
* WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR
* OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF
* ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
*
*
* IndexAndIndexBufferARB.cpp
*
*****************************************************************************/
#include <oz++/opengl/OpenGLMainView.h>
#include <oz++/opengl/OpenGLView.h>
#include <oz++/opengl/OpenGLGC.h>
#include <oz++/opengl/OpenGLLight.h>
#include <oz++/opengl/OpenGLMaterial.h>
#include <oz++/opengl/ColorNormalVertex.h>
#include <oz++/opengl/OpenGLVertex3.h>
#include <oz++/opengl/OpenGLClientState.h>
#include <oz++/openglarb/OpenGLVertexBufferARB.h>
#include <oz++/openglarb/OpenGLIndexBufferARB.h>
#include <oz++/opengl2/OpenGLVertexAttribute.h>
namespace OZ {
class MainView :public OpenGLMainView {
private:
//Inner class starts.
class SimpleView: public OpenGLView {
private:
OpenGLGC gc;
SmartPtr<OpenGLVertexBufferARB> vertexBuffer;
SmartPtr<OpenGLIndexBufferARB> indexBuffer;
int numVertices;
int numIndices;
public:
virtual void display()
{
if (vertexBuffer && indexBuffer) {
gc.clear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT);
gc.loadIdentity();
try {
gc.translate(0.0f,0.0f,-1.0f);
gc.lookAt(2.0, 4.0, 6.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0);
gc.clearColor(1.0f, 0.8f, 0.8f, 1.0f);
//OpenGLClientState constructor enables its argument, and the destructor disables its argument.
OpenGLClientState state1(GL_VERTEX_ARRAY);
OpenGLClientState state2(GL_COLOR_ARRAY);
OpenGLClientState state3(GL_NORMAL_ARRAY);
const GLfloat lightPosition[] = { 5.0, 5.0, -8.0 , 1.0 };
const GLfloat lightColor[] = { 1.0, 0.0, 0.0 , 1.0 };
const GLfloat materialColor[] = { 0.8, 0.8, 0.4 , 1.0 };
OpenGLLight light(GL_LIGHT0);
light.position(lightPosition);
light.diffuse(lightColor);
light.enable();
OpenGLMaterial material(GL_FRONT_AND_BACK );
material.diffuse(materialColor);
vertexBuffer -> bind();
indexBuffer -> bind();
gc.interleavedArrays(GL_C4F_N3F_V3F, 0, NULL);
gc.drawElements(GL_QUADS, numIndices, GL_UNSIGNED_INT, NULL);
vertexBuffer -> unbind();
indexBuffer -> unbind();
} catch (Exception& ex) {
caught(ex);
}
}
}
virtual void resize(int w, int h)
{
if (w == 0 || h == 0) {
return;
}
gc.matrixMode(GL_PROJECTION);
gc.loadIdentity();
gc.perspective(16.0, (double)w / (double)h, 0.5, 40.0);
gc.matrixMode(GL_MODELVIEW);
}
virtual void initialize()
{
gc.enable( GL_DEPTH_TEST );
/*
gc.matrixMode(GL_PROJECTION);
gc.loadIdentity();
gc.frustum(1 , -1 , -1 , 1 , 1 , 10);
gc.clearColor(0.0, 0.0, 1.0, 1.0);
*/
try {
static ColorNormalVertex<float,4,3,3> vertices[] = {
{ 0.5f, 0.0f, 0.0f, 0.5f, -0.6f, 0.6f, 0.6f, -0.5f, 0.5f, 0.5f },
{ 0.5f, 0.0f, 0.0f, 0.5f, -0.6f, -0.6f, 0.6f, -0.5f, -0.5f, 0.5f },
{ 0.5f, 0.0f, 0.0f, 0.5f, 0.6f, 0.6f, 0.6f, 0.5f, 0.5f, 0.5f },
{ 0.5f, 0.0f, 0.0f, 0.5f, 0.6f, -0.6f, 0.6f, 0.5f, -0.5f, 0.5f },
{ 0.5f, 0.0f, 0.0f, 0.5f, 0.6f, 0.6f, -0.6f, 0.5f, 0.5f, -0.5f },
{ 0.5f, 0.0f, 0.0f, 0.5f, 0.6f, -0.6f, -0.6f, 0.5f, -0.5f, -0.5f },
{ 0.5f, 0.0f, 0.0f, 0.5f, -0.6f, 0.6f, -0.6f, -0.5f, 0.5f, -0.5f },
{ 0.5f, 0.0f, 0.0f, 0.5f, -0.6f, -0.6f, -0.6f, -0.5f, -0.5f, -0.5f },
};
static GLuint indices[] = {
0, 2, 3, 1,
2, 4, 5, 3,
4, 6, 7, 5,
6, 0, 1, 7,
6, 4, 2, 0,
1, 3, 5, 7,
};
gc.clear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT);
gc.loadIdentity();
numVertices = SizeOf(vertices);
vertexBuffer = new OpenGLVertexBufferARB();
vertexBuffer -> bind();
vertexBuffer -> data(//sizeof(vertices),
numVertices*sizeof(ColorNormalVertex<float,4,3,3>),
vertices, GL_STATIC_DRAW_ARB);
vertexBuffer -> unbind();
numIndices = SizeOf( indices );
indexBuffer = new OpenGLIndexBufferARB();
indexBuffer -> bind();
indexBuffer -> data(numIndices*4, indices, GL_STATIC_DRAW_ARB);
indexBuffer -> unbind();
} catch (Exception& ex) {
caught(ex);
}
}
public:
SimpleView(OpenGLMainView* parent, const char* name, Args& args)
:OpenGLView(parent, name, args)
{
}
~SimpleView()
{
}
};
//Inner class ends.
private:
SmartPtr<SimpleView> view;
public:
MainView(OpenGLApplication& applet, const char* name, Args& args)
:OpenGLMainView(applet, name, args)
{
Args ar;
ar.set(XmNopenGLBufferType, (XtArgVal)getBufferType());
view = new SimpleView(this, "", ar);
}
~MainView()
{
}
};
}
//
int main(int argc, char** argv)
{
try {
const char* name = argv[0];
OpenGLApplication applet(name, argc, argv);
Args args;
args.set(XmNwidth, 400);
args.set(XmNheight, 300);
MainView view(applet, name, args);
view.realize();
applet.run();
} catch (Exception& ex) {
caught(ex);
}
return 0;
}
