/****************************************************************************** * * Copyright (c) 2019 Antillia.com TOSHIYUKI ARAI. ALL RIGHTS RESERVED. * * Redistribution and use in source and binary forms, with or without * modification, are permitted provided that the following conditions * are met: * 1. Redistributions of source code must retain the above copyright * notice, this list of conditions, and the following disclaimer. * * 2. The name of the author may not be used to endorse or promote products * derived from this software without specific prior written permission. * * THIS SOFTWARE IS PROVIDED BY THE AUTHOR ``AS IS'' AND ANY EXPRESS OR * IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES * OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. * IN NO EVENT SHALL THE AUTHOR BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, * SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, * PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; * OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, * WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR * OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF * ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. * * * BlurredMaterializedSpheres.cpp * *****************************************************************************/ //2019/01/03 #include <opencv2/stitching.hpp> #define String _XtString #include <oz++/StringT.h> #include <oz++/motif/RowColumn.h> #include <oz++/motif/PushButton.h> #include <oz++/opengl/OpenGLApplication.h> #include <oz++/opengl/OpenGLMainView.h> #include <oz++/opengl/OpenGLView.h> #include <oz++/opengl/OpenGLGC.h> #include <oz++/opengl/OpenGLTexture2D.h> #include <oz++/opengl/OpenGLBulletinBoard.h> #include <oz++/opengl/OpenGLLight.h> #include <oz++/opengl/OpenGLMaterial.h> #include <oz++/opengl/OpenGLSolidSphere.h> #include <oz++/opengl/OpenGLWireSphere.h> #undef String #include <oz++/opencv/OpenCVImageInfo.h> #include <oz++/opencv/OpenCVImageView.h> #include <oz++/opencv/OpenCVImageFileReader.h> namespace OZ { class MainView :public OpenGLMainView { public: private: //Inner OpenGLView class starts. class SimpleGLView: public OpenGLView { private: static const int SPHERES=4; OpenGLGC gc; SmartPtr<OpenGLGeometry> sphere[SPHERES]; float angle; public: virtual void display() { if (sphere[0]) { setPerspective(); gc.clear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT); gc.lookAt(4.0, 8.0, 12.0, 0.0, 0.0, 0.0, 0.0, 1.0, 0.0); gc.clearColor(0.0, 0.0, 0.0, 1.0); gc.enable(GL_CULL_FACE); gc.enable(GL_LIGHTING); OpenGLLight light(GL_LIGHT0); GLfloat lightPosition[] = {10, 10, 10, 1.0}; light.position(lightPosition); for (int i = 0; i<SPHERES; i++) { gc.pushMatrix(); gc.rotate(angle, 0.0f, 1.0f, 0.0f); sphere[i]->draw(&gc, -2.0f+1.3f*i, 0.5f, 0.0f+ 0.3f*i); gc.popMatrix(); } } } cv::Mat capture() { Dimension w = width(); Dimension h = height(); /* get(XmNwidth, (XtArgVal)&w); get(XmNheight, (XtArgVal)&h); */ w = (w/8)*8; glReadBuffer(GL_FRONT); glPixelStorei(GL_UNPACK_ALIGNMENT, 1); unsigned char* pixels = new unsigned char[3 * w * h]; glReadPixels(0, 0, w, h, GL_BGR, GL_UNSIGNED_BYTE, pixels); return cv::Mat(h, w, CV_8UC3, pixels); } virtual void resize(int w, int h) { if (w == 0 || h == 0) { return; } setPerspective(); } virtual void initialize() { Color4 black = { 0.0, 0.0, 0.0, 1.0 }; Color4 ambient = { 0.5, 0.5, 0.5, 1.0 }; Color4 diffuse = { 0.2, 0.4, 0.8, 1.0 }; Color4 specular = { 1.0, 1.0, 1.0, 1.0 }; Color4 emission = { 0.8, 0.0, 0.0, 0.0 }; GLfloat lowShining = { 10.0 }; GLfloat highShining = {100.0 }; OpenGLMateria mat1(GL_FRONT, ambient, diffuse, specular, emission, lowShining); OpenGLMateria mat2(GL_FRONT, black, diffuse, specular, emission, lowShining); OpenGLMateria mat3(GL_FRONT, black, diffuse, black, emission, highShining); OpenGLMateria mat4(GL_FRONT, ambient, diffuse, specular, black, highShining); OpenGLMateria materias[] = {mat1, mat2, mat3, mat4}; for (int i = 0; i<SPHERES; i++) { if (i%2 ==0) { sphere[i] = new OpenGLWireSphere(materias[i], 0.5f, 40, 40); } else { sphere[i] = new OpenGLSolidSphere(materias[i], 0.5f, 40, 40); } } } public: SimpleGLView(OpenGLBulletinBoard* parent, const char* name, Args& args) :OpenGLView(parent, name, args), angle(100.0f) { } }; //Inner OpenCVImageView class start class SimpleCVView: public OpenCVImageView { private: cv::Mat originalImage; cv::Mat blurredImage; cv::Mat scaledImage; public: virtual void display() { show(scaledImage); } public: SimpleCVView(OpenGLBulletinBoard* parent, const char* name, Args& args) :OpenCVImageView(parent, name, args) { } void blur(cv::Mat& originalImage) { int ksize = 13; int sigma = 10; ksize = (ksize/2)*2 + 1; blurredImage = cv::Mat::zeros(originalImage.size(), originalImage.type() ); //Blur operation is applied to the original image. cv::GaussianBlur(originalImage, blurredImage, cv::Size(ksize, ksize), (double)sigma, //sigmaX, (double)sigma); //sigmaY } void setImage(cv::Mat mat, bool flip=false) { try { cv::Mat flipped = mat; if (flip) {; cv::flip(mat, flipped, 0); originalImage = flipped; } originalImage = flipped; blur(originalImage); scaleImage(blurredImage, scaledImage, 80); invalidate(); refresh(); } catch (OZ::Exception& ex) { caught(ex); } } }; //Inner class ends. private: SmartPtr<OpenGLBulletinBoard> bboard; SmartPtr<RowColumn> controlPane; SmartPtr<SimpleGLView> glView; SmartPtr<SimpleCVView> cvView; SmartPtr<PushButton> captureButton; void resize(Dimension w, Dimension h) { int CP_WIDTH = 100; int ww = (w - CP_WIDTH)/2; if (glView && cvView && controlPane) { glView -> reshape(0, 0, ww-1, h); cvView -> reshape(ww+1, 0, ww-2, h); controlPane -> reshape(w-CP_WIDTH, 0,CP_WIDTH-2, h); } } void captureImage(Action& action) { cv::Mat image = glView->capture(); cvView->setImage(image, true); } public: MainView(OpenGLApplication& applet, const char* name, Args& args) :OpenGLMainView(applet, name, args.set(XmNopenGLBufferType, OpenGL_DOUBLE_BUFFER)) { Args ar; bboard = new OpenGLBulletinBoard(this, "", ar); ar.reset(); ar.set(XmNopenGLBufferType, (XtArgVal)getBufferType()); glView = new SimpleGLView(bboard, "", ar); ar.reset(); cvView = new SimpleCVView(bboard, "", ar); ar.reset(); controlPane = new RowColumn(bboard, "", ar); ar.reset(); captureButton = new PushButton(controlPane, "Capture", ar); captureButton->addCallback(XmNactivateCallback, this, (Callback)&MainView::captureImage, NULL); sendConfigureEvent(); } ~MainView() { } }; } // int main(int argc, char** argv) { try { glutInit(&argc, argv); const char* appclass = argv[0]; OpenGLApplication applet(appclass, argc, argv); Args args; args.set(XmNwidth, 900); args.set(XmNheight, 400); MainView view(applet, argv[0], args); view.realize(); applet.run(); } catch (OZ::Exception& ex) { caught(ex); } return 0; }
