SOL4Py Sample: GaussianBlur

SOL4Py Samples



#******************************************************************************
#
#  Copyright (c) 2018-2019 Antillia.com TOSHIYUKI ARAI. ALL RIGHTS RESERVED.
#
#    This program is free software: you can redistribute it and/or modify
#    it under the terms of the GNU General Public License as published by
#    the Free Software Foundation, either version 3 of the License, or
#    (at your option) any later version.
#
#    This program is distributed in the hope that it will be useful,
#    but WITHOUT ANY WARRANTY; without even the implied warranty of
#    MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
#    GNU General Public License for more details.
#
#    You should have received a copy of the GNU General Public License
#    along with this program.  If not, see <http://www.gnu.org/licenses/>.
#
#******************************************************************************


# GaussianBlur.py

# encodig: utf-8

import sys
import os
import cv2
import traceback


from PyQt5.QtCore    import *
from PyQt5.QtWidgets import *
from PyQt5.QtGui     import *

#
sys.path.append('../')

from SOL4Py.ZApplicationView import *
from SOL4Py.ZLabeledComboBox import ZLabeledComboBox
from SOL4Py.ZLabeledSlider   import ZLabeledSlider
from SOL4Py.opencv.ZOpenCVImageView import ZOpenCVImageView
from SOL4Py.ZVerticalPane    import ZVerticalPane


class MainView(ZApplicationView):
  # Inner classes
  #--------------------------------------------
  class SourceImageView(ZOpenCVImageView):
    def __init__(self, parent):
      ZOpenCVImageView.__init__(self, parent)

    def load(self, filename):
      self.load_openv_image(filename)
      self.update()

  class BlurredImageView(ZOpenCVImageView):
    def __init__(self, parent):
      ZOpenCVImageView.__init__(self, parent)
      self.source_image = None

    def load(self, filename):
       self.load_openv_image(filename)
       #self.source_image = image.copy()

    def blur(self, ksize, sigma):
      ksize = int(ksize)
      source_image = self.get_opencv_image()

      if source_image.all() != None:
        blurred_image = cv2.GaussianBlur(source_image, (ksize, ksize),
            float(sigma), #sigmaX
            float(sigma)) #sigmaY

        self.set_opencv_image(blurred_image)
        self.update()

  #--------------------------------------------



  # MainView Constructor
  def __init__(self, title, x, y, width, height):
    super(MainView, self).__init__(title, x, y, width, height)

    filename = "../images/flower.png"

    # 1 Create first imageview.
    self.source_image_view = self.SourceImageView(self)

    # 2 Create second imageview.
    self.blurred_image_view = self.BlurredImageView(self)

    # 3 Load the file
    self.load_file(filename)

    # 4 Add two image views to a main_layout of this main view.
    self.add(self.source_image_view)
    self.add(self.blurred_image_view)

    self.show()

  # Add control pane to MainView
  def add_control_pane(self, fixed_width=200):
    # Control pane widget
    self.vpane = ZVerticalPane(self, fixed_width)

    self.ksize = 11

    self.ksize_slider = ZLabeledSlider(self.vpane, "KernelSize", take_odd =True,
              minimum=0, maximum=31, value=self.ksize)
    self.ksize_slider.add_value_changed_callback(self.ksize_value_changed)

    self.vpane.add(self.ksize_slider)

    self.sigma = 12
    self.sigma_slider = ZLabeledSlider(self.vpane, "SigmaSize", take_odd =True,
              minimum=0, maximum=33, value=self.sigma)
    self.sigma_slider.add_value_changed_callback(self.sigma_value_changed)

    self.vpane.add(self.sigma_slider)

    self.set_right_dock(self.vpane)


  # Show FileOpenDialog and select an image file.
  def file_open(self):
    options = QFileDialog.Options()
    filename, _ = QFileDialog.getOpenFileName(self,"FileOpenDialog", "",
                     "All Files (*);;Image Files (*.png;*jpg;*.jpeg)", options=options)
    if filename:
      self.load_file(filename)

  def load_file(self, filename):
    self.source_image_view.load_opencv_image(filename,  cv2.IMREAD_COLOR)
    self.blurred_image_view.load_opencv_image(filename, cv2.IMREAD_COLOR)
    self.blurred_image_view.blur(int(self.ksize), int(self.sigma) )
    self.set_filenamed_title(filename)

  # Slider value changed callback.
  def ksize_value_changed(self, value):
    self.ksize = int(value)
    if self.ksize % 2 == 0:
      self.ksize = (self.ksize * 2)/2 + 1
      # Kernel size should be odd.
    #print("slider_value_changed:{}".format(ksize))
    self.blurred_image_view.blur(int(self.ksize), int(self.sigma) )

  # Slider value changed callback.
  def sigma_value_changed(self, value):
    self.sigma = int(value)
    #print("slider_value_changed:{}".format(ksize))
    self.blurred_image_view.blur(int(self.ksize), int(self.sigma) )

#*************************************************
#
if main(__name__):
  try:
    app_name  = os.path.basename(sys.argv[0])
    applet    = QApplication(sys.argv)

    main_view = MainView(app_name, 40, 40, 900, 380)
    main_view.show ()

    applet.exec_()

  except:
    traceback.print_exc()


Last modified: 22 Mar. 2019
